K29 is a two piece single acting
buffer seal which consists of onespecial designed elastomeric
sealing element for to evacuatethe back pressure and one
thermoplastic back-up ring.
• No pressure build up between the primary and secondary seal
• High wear resistance
• Low friction
• Low axial housing heights
• Good protection to the secondary seal with pressure peaks
Construction machinery , fork-lift trucks , injection mouldingmachines , agricultural machinery , cranes , earth movingequipment and standard cylinders.
|PU||92 SHORE A||PU9201|
Mineral oils(DIN 51524)
HFA ve HFB
|TEMPERATURE||-40°C +100°C||+5°C +50°C||-30°C +40°C|
|PRESSURE||≤400 Bar||≤400 Bar||≤400 Bar|
|SPEED||≤0.5 m/sn||≤0.5m/sn||≤0.5 m/sn|
